ZHENHUAN has subsequently launched various 5 in 1 dimming type, 4 in 1 dimming type, Triac/phase-cut dimming type and Non-dimming outdoor led driver for Residential, Commercial, and Industrial LED lighting applications, including 40W~320W products in the HP&HO&HT&H product series (details refer to table below), black color with junction box or wiring compartments with Knock-Outs for Clean and Easy Installation. ZHENHUAN is now launching the new silver color product series to cover more application power requirements.
Key product features include: ultra-wide 100-277v ac input range that covers common voltages used globally in LED applications (12V /24V /36V /48V), electronic Class 2, Class P, TYPE HL, UL/cUL CE Listed featuring 2K frequency PWM output dimmable LED drivers available with an integrated junction box and with multiple dimming options. Supporting hiccup mode, over current and short circuit protection, as well as an efficiency over >84% resulting in a low operating case temperature. IP65 waterproof environment protection rated for indoor or outdoor use, high PFC function more than 0.92 and provide 5 years warranty. The versatility of the HP&HO&HT&H Series makes it the perfect choice for tape lighting, tube lighting, linear lighting and multiple other commercial and residential applications.
Outdoor Dimmable LED Driver for Residential, Commercial, and Industrial LED lighting
Mounting Type
Color
Input Voltage(V)
Output Watt(W)
Safety
Series Name
HP
HO
HT
H
With Junction box
Black
100-277VAC
40W ~ 320W
UL/cUL 8750;CE 61347, TUV-GS, Class 2, Class P, SELV
5 In 1 dimming (0/1-10v, triac, 10v pwm, resistor)
4 In 1 dimming (0/1-10v, triac, 10v pwm, resistor)
Triac / Phase-cut dimming
Non-dimming
Wiring compartments with Knock-Outs
Black
Wiring compartments with Knock-Outs
Silver
Features:
- Input Voltage: Universal 100VAC to 277VAC, 50/60Hz for Residential, Commercial, and Industrial Use
- Single Channel & Constant Voltage mode
- Output Voltage: 12Volt, 24Volt, 36Volt, or 48Volt options
- Driver Type: Class 2 Class P
- Enclosure:LISTED Enclosure with Junction Box / LISTED Enclosure without Junction Box
- Dimming: PWM, TRIAC, 0/1-10V or MLV / ELV Resistor Dimmable Available
- Environmental: Dry and Damp
- Wiring Compartments with Knock-Outs for Clean and Easy Installation
- Current Limiting Overload Protection
- Flicker-Free
- Smooth Ripple Free Output Voltage
- IP67 Rated Enclosure for Indoor and Outdoor Use
- 5 Years Warranty
- UL/cUL CE FCC RoHS ENEC GS Listed, SELV, Type HL
